A Subpolar Measure of the Atlantic Meridional Overturning Circulation

OSNAP is an international program designed to provide a continuous record of the full-water column, trans-basin fluxes of heat, mass and freshwater in the subpolar North Atlantic. The OSNAP observing system consists of two legs: one extending from southern Labrador to the southwestern tip of Greenland across the mouth of the Labrador Sea (OSNAP West), and the second from the southeastern tip of Greenland to Scotland (OSNAP East).

The observing system also includes subsurface floats (OSNAP Floats) in order to trace the pathways of overflow waters in the basin and to assess the connectivity of currents crossing the OSNAP line.

Read the OSNAP blog for stories, events, scientific updates, and more!

OSNAP MOC Timeseries

The 30-day mean MOC from 2014 to 2018 is derived for the full array (16.4 ± 0.6 Sv, mean±uncertainty), the OSNAP West (2.6 ± 0.3 Sv) and OSNAP East (16.4 ± 0.6 Sv) subsections. This figure is adopted from Li et al. (2021), please refer to their work for details. The OSNAP MOC and derived heat and freshwater transport can be accessed here.

Latest OSNAP Timeseries and Seasonal Cycle

Disclaimer: The poster below shows an unpublished OSNAP dataset (2018 to 2020). Thus, the values in the preliminary analysis below may change due to upcoming data updates.
